PVC cling film blown line (the only domestic manufacturer)
- Name:
PVC cling film blown line (the only domestic manufacturer)
- Model: 2008
Contact Us
Quick Detail:
This production line manufactures PVC film by blowing method.It has three characters:
1.The diaphragm is thin . And its minimum is up to 0.006mm.
2.The coil diameter is big. Each is between 6000m-9000m.Suitable for plant using packaging and split charging.
3.High yield.
High quality
High performance ( film thickness: 0.006mm-0.011mm,
film length:6000m-9000m )
High capacity ( more than 400kg / h )
Low loss(all scrap recycling)
Main technical parameters
| Model | 2800 |
| Screw Diameter (mm) | Φ120 |
| L/D Ratio of Screw | 28:1 |
| Rotation die orifice diameter (mm) | Φ250 |
| Width of Finished Film (mm) | 2300×2 |
| Thickness of Finished Film (mm) | 0.006-0.010 |
| Max.Extrusion Capacity (kg/h) | 450 |
| Design Line Speed (m/min) | 160 |
| Total Installed Power (kw) | 300 |
| Overall Dimensions(L×W×H) (m) | 30×8×13 |
| Weight (T) | 85 |
The above technical data will be changed without noticed.
